Messier’s nebulous objects


Besides the (only) 4 planetary nebulae in the Messier list there are some more types of nebulous objects. These are emission nebulae, nebulous clusters and even a supernova remnant. Only M42 and M43 will be treated in an own section “Zooming into M42“.


M17 is a masterpiece of the sky, but unfortunately it’s low in my sky at a time that we in the north have to endure the so called “grey nights”. Therefore I used some of my time on La Palma with the 10″ Alkaid to observe and sketch it. Besides the easily recognizable figure of the swan, a lot of “smokiness” around it can be seen as well, especially with the use of an OIII filter. The latter also helped to dim many of the stars just enough so that the main focus could remain on the actual object. Sketched with the 10″ Alkaid @120x.

sketch messier 17 m17 swan nebula


M27 is the famous Dumbbell Nebula. I waited with sketching this fine object until I could view it under a dark and transparent sky to sketch as many stars as I could. Therefore most of the observation was done unfiltered. The nebula is then very softly defined, but the dumbbell shape is quite apparent and in every corner a “loop” is visible, especially the one down and left. The brightness is not evenly distributed, but most visible in the top left, where a separate fragment is seen close to a bright star. Cutting through the center is a dark band, dividing the dumbbell into two sections. An UHC filter was applied sometimes to get a better definition of the shape. This must be (one of) the finest planetary nebulae the sky has to offer! Sketched with the 16″ Alkaid @259x.

sketch M27 dumbbell nebula


M57 is for sure one of the most sketched objects and I must say that I hardly ever skip it while observing during a summer night. For the central star and nearby galaxy IC 1296 however, the sky must be dark and transparent while the seeing has to cooperate too. I found those three conditions during a summer holiday session in Bretagne (France) so that I could finally make a proper drawing of the Ring Nebula. Sketched with the 16″ Alkaid @259x.

sketch messier 57 m57 ring nebula


Another famous planetary nebula in the Messier Catalog is M76 in Perseus. After trying different magnifications, I settled for the 7mm + OIII filter. The “cork” is easily visible, but also two “hooks” can be seen, albeit much dimmer. Sketched with the 16″ Alkaid @259x.

sketch messier 76 m76 little dumbbell


M78 is a reflection nebula, so I observe it without any filter. It is seen as a large, mottled glow around 2 bright stars and is sharply edged and serrated on that side. NGC 2071 (down in the sketch) is not seen as a uniform glow as well, but it shows three tentacles. Furthermore, parts of NGC 2067 and NGC 2064 are observed, some of them with effort with AV. This part of the sky proves to be a nice complex of nebulosity! Sketched with the 16″ Alkaid @91x.

sketch m78


M97, the Owl Nebula, is very large and bright, but the characteristics are quite subtle. The “eyes” as such are not directly seen, but are rather visible as a dark beam cutting through the center. The central star is not seen at all times, but can be seen blinking now and then, so it’s actually quite dim. Then, after a bit longer observation it becomes clear that the area around the CS is brighter and that the eyes are indeed separated, differing in size, brightness and shape. Left and right of the upper eye and CS, the nebulosity is just a tad brighter. The shape of the nebula is almost a perfect circle, but just a little bit flatter on the right side. The nebula is nicely captured in a large “V” of stars. Sketched with the 16″ Alkaid @259x.

sketch m97 owl nebula
